TImageEnView.PdfViewer

Declaration

property PdfViewer: TIEPdfViewer;

Description

Provides access to the properties of the TIEPdfViewer class, which allows viewing, editing and saving of PDF files (once Enabled).



Features

• Scaling and auto-fit options
• View all pages at once *
• Page and document rotation
• User editing of form fields
• Programmatically read and set form field values
• User editing of page objects with clipboard support *
• Programmatically read and modify page objects and annotations
• Importing, Exporting, adding, deleting and moving of pages
• Saving of changed PDF files
• Selection of text and images * with clipboard support
• Text searching and highlighting
• High quality printing and exporting to bitmap and text
• Bookmark display and Page thumbnail viewer with one-click navigation *
• Access to file attachments
• Keyboard shortcuts
• Web Link and Page Link support
• Display navigation buttons and PDF annotations
• Actions for rapid development

* Custom ImageEn features (not available in standard PDFium)

Note:
◼PDFium support requires Delphi/BCB 7 or newer
◼The PDFium plug-in DLL must exist in the same folder as your application EXE. You can download it from: www.imageen.com/download/
◼Read more about ImageEn PDF Support
◼You cannot use the PdfViewer with multiple layers
◼The size of the PDF page as displayed on-screen and when output to bitmap is controlled by IEGlobalSettings().PdfViewerDefaults.DPI

Mouse Interactions

Typically the following mouse interactions are used with PdfViewer:

When enabling PdfViewer, MouseInteractGeneral will be set to [miPdfSelectText, miPdfSelectRgn]. You can edit objects using miPdfSelectObject, and annotations using miPdfSelectAnnotation. miPdfSelectRgn, miPdfSelectObject and miPdfSelectAnnotation have no effect if ShowAllPages is enabled.
The following interactions are supported: miPdfSelectText, miScroll, miZoom, miSmoothZoom, miDblClickZoom, miMovingScroll. If not showing all pages, you can also use: miPdfSelectRgn, miSelectZoom, miSelect, miSelectPolygon, miSelectCircle, miSelectMagicWand, miSelectLasso, miSelectChromaKey
All layer interactions are disabled.
You can also use the mouse to edit form fields if you enable AllowFormEditing.

Keyboard Shortcuts

Page Editing

Users can edit objects in a PDF page if you set MouseInteractGeneral to [miPdfSelectObject] and enable AllowObjectEditing, and edit annotations by setting MouseInteractGeneral to [miPdfSelectAnnotation] and enabling AllowAnnotationEditing.

When editing is enabled:
◼Objects and annotations can be selected
◼Selected objects can be size and moved (by mouse or cursor keys)
◼Pressing Delete will remove the current object
◼Clipboard operations are supported, including pasting text or images from the clipboard (objects only, not annotations)

Demos

Examples

// Register the PDFium Plug-In
IEGlobalSettings().RegisterPlugIns([ iepiPDFium ]);

// Display a PDF document (and allow text and image selection, scaled viewing, etc)
ImageEnView1.PdfViewer.Enabled := True;
ImageEnView1.MouseInteractGeneral := [ miPdfSelectText, miPdfSelectRgn ];
ImageEnView1.IO.LoadFromFilePDF( 'C:\document.pdf' );

// Show all pages at once
ImageEnView1.PdfViewer.ShowAllPages := True;




// Enable form editing
ImageEnView1.PdfViewer.Enabled := True;
ImageEnView1.PdfViewer.AllowFormEditing := True;
ImageEnView1.IO.LoadFromFilePDF( 'C:\document.pdf' );





// Allow user to select images or text and copy to clipboard (automatically detecting selection based on what is under the cursor)
ImageEnView1.MouseInteractGeneral := [ miPdfSelectText, miPdfSelectRgn ];
ImageEnView1.PdfViewer.Enabled := True;

// Allow user to select text and copy to clipboard (image selection disabled)
ImageEnView1.MouseInteractGeneral := [ miPdfSelectText ];
ImageEnView1.PdfViewer.Enabled := True;

// Allow user to select images and copy to clipboard (text selection disabled)
ImageEnView1.MouseInteractGeneral := [ miPdfSelectRgn ];
ImageEnView1.PdfViewer.Enabled := True;




// Display a PDF document and allow editing of the page objects and annotations
ImageEnView1.PdfViewer.Enabled := True;
ImageEnView1.MouseInteractGeneral := [ miPdfSelectObject, miPdfSelectAnnotation ];
ImageEnView1.PdfViewer.AllowObjectEditing := True;
ImageEnView1.IO.LoadFromFilePDF( 'C:\document.pdf' );

// Merge two PDF documents
ImageEnView1.PdfViewer.Enabled := True;
ImageEnView1.IO.LoadFromFilePDF( 'C:\document.pdf' );
ImageEnView1.PdfViewer.ImportPages( 'C:\morepages.pdf' );
ImageEnView1.IO.SaveToFilePDF( 'C:\merged.pdf' );

// Move pages to the start of the document
ImageEnView1.PdfViewer.MovePages( [3, 4, 8, 9], 0);

// Delete pages from the document
ImageEnView1.PdfViewer.DeletePages([ 5, 6 ]);

// Prompt user to save changes
if ImageEnView1.PdfViewer.DocModified then
  if MessageDlg( 'Save doc changes?', mtConfirmation, [ mbYes,mbNo ], 0 ) = mrYes then
    ImageEnView1.IO.SaveToFilePDF( ImageEnView1.IO.Params.Filename );

// Rotate document right for display
ImageEnView1.PdfViewer.PageRotation := iepr90Clockwise;

// Find and select the text "Adobe"
ImageEnView1.PdfViewer.Find( 'Adobe' );

// Highlight the text "Adobe" thoughout the document
ImageEnView1.PdfViewer.HighlightText( 'Adobe' );

// Copy all text in the page to the clipboard
ImageEnView1.PdfViewer.SelectAll();
ImageEnView1.PdfViewer.CopyToClipboard();

// Save all text in the page to a file
ss := TStringList.Create;
ImageEnView1.LockPaint();
ImageEnView1.PdfViewer.SelectAll();
ss.Text := ImageEnView1.PdfViewer.SelText;
ImageEnView1.PdfViewer.ClearSelection();
ImageEnView1.UnlockPaint();
ss.SaveToFile( 'D:\Page.txt' );
ss.Free();

// Show thumbnail preview of all pages of a PDF document
ImageEnView1.PdfViewer.Enabled := True;
ImageEnMView1.AttachedImageEnView := ImageEnView1;
ImageEnView1.IO.LoadFromFilePDF( 'C:\document.pdf' );




// Display a PDF document and allow editing of the page objects and annotations
ImageEnView1.PdfViewer.Enabled := True;
ImageEnView1.MouseInteractGeneral := [ miPdfSelectObject, miPdfSelectAnnotation ];
ImageEnView1.PdfViewer.AllowObjectEditing := True;
ImageEnView1.IO.LoadFromFilePDF( 'C:\document.pdf' );

See Also

◼PDFium PlugIn
◼PdfViewerDefaults

---
